Ralf Schuh's home page

In the picture above you can see Shan at the far end,

John staying on the right and myself sitting in front of the computer.

For remembering the good old days in the tunnel where we twisted the fibre until it told us the truth.

Biography

Some steps in my life have been: Polytechnic Dieburg in Germany where I received my diploma degree in Electronics 1992, M.Sc. degree in Optical Electronics from the University of Strathclyde , UK in 1993. From 1993 to 1997 I worked as a senior research officer at the University of Essex , UK, were I was awarded a Ph.D. degree in 1998 on the measurement and analysis of birefringence in optical fibres. From 1998 to 1999 researched work at the German national research center for open communication systems, GMD FOKUS , Berlin with mobile-ATM and wireless technologies in the access network. Currently I am with TeliaSonera AB in Sweden working with GSM/GPRS and WCDMA planning for indoor coverage and capacity.

Research areas:

Current: Indoor planning for GSM/GPRS and WCDMA
Some time ago: Software radio, hybrid fibre radio and multimode base stations, Mobile-ATM and related protocols. Investigated the limiting factor of polarisation mode dispersion (PMD), and its reduction, in high bit rate optical transmission systems. Developed a highly sensitive Polarimeter for measuring PMD in optical fibres and novel development of a Polarimetric Optical Time Domain Reflectometer (POTDR) to measure the PMD and state of polarisation evolution along a fibre. The industrial partners have been BT Laboratories , Ipswich, UK and Alcatel Submarine Networks , Greenwich, London, UK.

Publications (Journal papers, conferences, invited tutorials and patents):

Ralf Schuh, “TeliaSonera Case Study: Comparing The Technical And Commercial Benefits Of Potential Solutions To Deliver Dedicated GSM, WCDMA And WiFi Coverage”, IIR In-building solutions 2007, Dubai, United Arab Emirates, 18^thto ^rd October 2007 21^st November 2007
Ralf Schuh, “Dedicated Indoor Solutions: Considering GSM,WCDMA and WLAN in Offices”, Informa telecoms & media, Cannes, France, 2^nd to 3^rd October 2007
Ralf Schuh, “TeliaSonera Case Study: Comparing The Technical And Commercial Benefits Of Potential Solutions To Deliver Dedicated GSM, WCDMA And WiFi Coverage”, IIR In-Building & Enhanced Coverage Solutions, Amsterdam, The Netherlands, 24^th May 2007
Ralf Schuh, “Comparing The Different Technology Options For Meeting Indoor Coverage and Capacity Demands In 3G Networks”, IIR’s Mobile Network Optimisation – Africa, Cape Town, South Africa, 27 February – 2 March 2006
Ralf Schuh, “Highlighting the Specific Design and Measurement Challenges Faced when Developing WCDMA Indoor Networks”, In-building Solutions, IIR Telecoms & Technology, 23 - 26 May 2005, Munich.
Ralf Schuh and Fredrik Radencrantz, “Planning In-Building Coverage To Maximise Capacity In Traffic Hotspots”, Maximising Capacity in GSM, GPRS, EDGE & WCDMA Networks, IIR, 6 - 9 December 2004, Lisbon.
Ralf Schuh and Robert McCrorey, “Planning 3G In-Building Coverage For Traffic Hotspots”, 3G Radio Networks, Lisbon, IIR, Portugal 21 – 23 September 2004.
Ralf Schuh and Robert McCrorey, “Ericsson / TeliaSonera Case Study: Examining Indoor WCDMA Trial Experiences in Kista, Sweden”, IIR In-building Solutions, Budapest, Hungary 21 – 25 June 2004.
Ralf E. Schuh, Robert Andersson, Andre Stranne, Magnus Sommer and Peter Karlsson, “Interference Analysis for Dedicated Indoor WCDMA Systems”, VTC2003-Fall, Orlando, Florida, USA October 6-9, 2003.
R. E. Schuh, "Successfully integrating indoor picocellular solutions with the surrounding outdoor network," IIR's European Summit 2003, In-building Coverage, Invited talk, Lisbon, Portugal, 8 - 10 April 2003.
R.E. Schuh, A. Alping and E. Sundberg, “Penalty-free GSM-1800 and WCDMA radio-over-fibre transmission using multi-mode fibre and 850 nm VCSEL”, IEE Electronics Letters, vol. 39, no. 6, pp. 512-514, 2003.
Ralf E. Schuh, Erland Sundberg, Bertil Verri and Tommy Arkner , "Penalty free simultaneous 1 Gbit/s digital and GSM-1800 radio signal transmission over 600 m multimode fibre using 850 nm VCSEL sources," PIMRC 2002, Lisbon, Portugal, ISBN: 0-7803-7589-0, pp. 2274-2276, September 15 - 18, 2002.

Ralf Schuh and Magnus Sommer, "Adaptive passive distributed antenna system," Patent, Telia AB (SE), SE0203557 (L), WO2004051804 (A1), SE525090, 2004-11-30.

R. Schuh, P. Eneroth, P. Karlsson, and C. Bergljung, "Base stations and mobile terminals: How much reconfigurability do we want?," Second European Colloquium on Reconfigurable Radio Athens, Invited talk Panel discussion on – The challenges of Reconfigurability, Greece, 20-22 June, 2002
Ralf E. Schuh, Peter Eneroth and Peter Karlsson, "Multi-Standard Mobile Terminals," IST Mobile & Wireless Telecom. Summit 2002, ISBN: 960-91918-0-0, pp. 174-178, 16-19 June 2002, Thessaloniki - Greece.
R. E. Schuh, "Radio-over-Fiber for 3G systems," Swedish Microwave Photonics Workshop –2002, SMWP´2002, Invited talk, Göteborg, Sweden, 28 - 29 May, 2002 .
R. Schuh and M. Sommer, " W-CDMA Coverage and Capacity Analysis for Active and Passive Distributed Antenna Systems," VTC Spring 2002, Birmingham, USA, May 6 - 10, 2002.
Ralf. E. Schuh, Erland Sundberg and Arne Alping, "W-CDMA signal transmission over multimode fibre using 850 nm VCSEL," Wireless Design Conference (WDC) 2002, ISBN 0862131987, London, UK, pp. 47-50, 15 – 17 May 2002
R. E. Schuh, "Developing a migration strategy for implementing a 3G indoor coverage solution macrocellular and dedicated in-building in hotspots," IIR's European Summit 2002, In-building Coverage, Invited talk, Barcelona, Spain, 22 - 26 April 2002.
D. Wake and R. E. Schuh , "Examining Experiences of Planning In-Building Solutions for 3G networks ," IIR's European Summit 2001, In-building Coverage, Invited talk, Prague, Czechoslovakia , 26 - 28 Nov 2001.
R. E. Schuh, D. Wake and E. Sundberg, "A simple linearity analysis for active distributed antenna systems using W-CDMA signals," Microwave Photonics MWP'01, Long Beach, California, ISBN: 0-7803-7003-1, pp. 113-116, October 7 – 10, 2001 (January 7-9, 2002).
R. E. Schuh, "Radio over fibre for telecommunications," Workshop invited contribution, Microwave Photonics MWP'01, Long Beach, California, October 7, 2001.

A. Karlsson, R. Schuh C. Bergljung, P. Karlsson and N. Löwendahl, "The influence of trees on radio channels at frequencies of 3 and 5 GHz," IEEE 54th VTC Fall 2001, Atlantic City, USA, October 7 – 11, 2001.
R. E. Schuh, "Case study: Comparing active and passive solutions for distributed antenna systems in a 3G environment," IIR's European Summit 2001, In-building Coverage, Invited talk, Marbella ,Spain, 5 - 8 June 2001.

Ralf Schuh, Erland Sundberg, Bertil Verri and Tommy Arkner, "An interface for local area networks," Patent, Telia AB (SE), SE0102978 (L)/SE523065 (C2)/EP1428351 (A1)/ WO03024027 (A1), 2003-03-20.

P. Karlsson, C. Bergljung, Anders Karlsson, N. Löwendahl and R. Schuh, "Wideband Spatial Propagation in the 3 GHz and 5 GHz Bands for Evaluation of WLL and RLAN Systems," Third International Symposium on Wireless Personal Multimedia Communications, WPMC’00, pp. 320 – 325, Bangkok, Thailand, 12 – 15 November 2000

R. Schuh and P. Emanuelsson, "Mobile base station system where the central unit and the antenna units are separated from each other," Patent, SE 0003610-3, Telia Research AB, 11 August 2000 and WO0230141, Telia AB (SE), 2002-04-11.

R. E. Schuh, D. Wake, B. Verri and E. Sundberg, "Penalty free W-CDMA radio signal transmission over fibre," Microwave Photonics 2000, MWP 2000, Oxford, England, 11 - 13 September, 2000.
D. Wake and R. E. Schuh, "Optical fibre links for third generation mobile networks," Invited paper, 26th European Conference on optical communication, ECOC 2000, Munich, Germany, ISBN: 3-8007-2567-3, pp. 89-90, September 4 - 7, 2000.
D. Wake and R. E. Schuh, "Measurement and simulation of W-CDMA signal transmission over optical fibre," IEE Electronics Letters, vol. 36, no. 10, pp. 901-902, 2000.

From my time at GMD FOKUS:

R. E. Schuh and D. Wake, "Software defined radio and hybrid fibre radio for low cost radio independent wireless access," IEEE International Conference on Third Generation Wireless Communications, IEEE 3gWireless'2000, pp. 48-51, ISSN No.: 1529-2592 (2000), Delson Group Inc., San Francisco, Silicon Valley, USA, June 14 - 16, 2000.
R. E. Schuh and D. Wake, "Distortion of W-CDMA signals over optical fibre links," Technical Digest, International Topical Meeting on Microwave Photonics – MWP'99, Post deadline paper, Session F-12, pp. 9-12, ISBN 0-7803-5558-X, Melbourne, Australia, November 17 – 19, 1999.
R. E. Schuh , "Hybrid fiber radio for second and third generation wireless systems,” Technical Digest Microwave Photonics '99, MWP'99, ISBN: 0-7803-5558-X, Melbourne, Australia, pp. 213-216, 17-19 November 1999
R. E. Schuh, C. Schuler and M. Mateescu, "An architecture for radio-independent wireless access networks," Proceedings 49th IEEE Annual International Vehicular Technology Conference, VTC'99, Houston, Texas, USA, vol. 2, pp. 1227 - 1231, 16 - 19 May, 1999.
R. E. Schuh, D. Wake, B. Verri and M. Mateescu, "Hybrid Fibre Radio Access: A Network Operators Approach and Requirements," Proceedings 10th Microcoll, Microcoll'99, Budapest, Hungary, ISBN: 963 420 594-1, pp. 211-214, 21-24 March, 1999.

· R. E. Schuh and H. Brandt, "Simple mobile-ATM," Proceedings of 5th Int. Workshop on Mobile Multimedia Communication MoMuC'98, pp. 345-348, Berlin, Germany, Oct. 12 - 14, 1998.

(Slides to: Simple mobile-ATM)

From my University time:

X. Shan, R. E. Schuh, A. Altuncu, A. S. Siddiqui, "Polarisation mode dispersion in distributed erbium doped fibres," Optical Fiber Technology, vol. 5, pp. 75-81, 1999.
R. E. Schuh, X. Shan and A. S. Siddiqui, "Polarisation mode dispersion in spun fibres with different linear birefringence and spinning parameters," Journal of Lightwave Technology, vol. 16, no. 9, pp. 1583-1588, 1998.
R. E. Schuh, A. S. Siddiqui, X. Shan, J. G. Ellison and D. H. O. Bebbington, "A novel simple polarisation OTDR technique to detect fibre sections with and without twist," International Journal of Optoelectronics, vol. 11, no. 5, pp. 335-338, 1997.
R. E. Schuh and A. S. Siddiqui, "A single channel polarimetric OTDR for the measurement of the backscattered SOP evolution along a fibre with twist," Electron. Lett. vol. 33, no. 25, pp 2153-2154, 1997.
R. E. Schuh, X. Shan, A. S. Siddiqui, E. S. R. Sikora, Measurement and analysis of PMD in spun fibres with different linear birefringence and spinning parameters," 4th Optical Fibre Measurement Conference, OFMC'97, NPL, Teddington, UK, 29th Sep.- 1st Oct. 1997.
R. E. Schuh, A. Altuncu, X. Shan, A. S. Siddiqui, "Measurement and theoretical modelling of polarisation mode dispersion in distributed erbium doped fibres," ECOC'97, We3, Edinburgh, UK, pp. 203 - 206, 1997.
R. E. Schuh, A. Altuncu, X. Shan, A. S. Siddiqui, "Polarisation mode dispersion in distributed erbium doped fibres for ultrahigh bit rate long haul soliton transmission," First International Conference on polarisation effects in laser and spectroscopy, Toronto, Canada, 26-28 May 1997.
D. H. O. Bebbington, J. G. Ellison, R. E. Schuh, X. Shan, A. S. Siddiqui, S. D. Walker, "A polarimetric optical time domain reflectometer", Proc. IOP conference on Applied Optics and Opto-Electronics, Post deadline paper, PD 2, Reading, September 18, 1996.
D. H. O. Bebbington, J. G. Ellison, R. E. Schuh, X. Shan, A. S. Siddiqui, S. D. Walker, "Fully Polarimetric Optical Time Domain Reflectometer with one meter Spatial Resolution," OFC'97, WL24, Dallas, 1997.
R. E. Schuh and A. S. Siddiqui, "Measurement of SOP evolution along a linear birefringent fibre with twist using polarisation OTDR," Symposium on Optical Fiber Measurements, Tech. Digest, NIST special publication 905, pp 159-162, Boulder, 1996.
R.E. Schuh, J. G. Ellison, A. S. Siddiqui, D. H. O. Bebbington, "Polarisation OTDR measurements and theoretical analysis on fibres with twist and their implications for estimation of PMD", Electron. Lett. vol. 32, no. 4, pp 387-388, 1996.
R.E. Schuh, J. G. Ellison, L. M. Gleeson, E. S. R. Sikora, A. S. Siddiqui, N. G. Walker, D. H. O. Bebbington, "Theoretical analysis and measurement of the effect of fibre twist on the polarisation optical time domain reflectometry of optical fibres," OFC'96, FA5, San Jose, 1996.
R.E. Schuh, E. S. R. Sikora, N. G. Walker, A. S. Siddiqui, L. M. Gleeson, D. H. O. Bebbington, "Theoretical analysis and measurement of the effects of fibre twist on the polarisation mode dispersion of optical fibres," Electron. Lett. vol. 31, no. 20, pp 1772-1773, 1995.
